Mechanical Shaker Table XYZ Axis High Frequency Vibration Tester
Professional electrodynamic vibration testing system capable of performing sinusoidal vibration tests, broadband random vibration tests, classical pulse tests, and shock response spectrum tests in X, Y, Z three-axis configurations.
Advanced Technology Features
Our high frequency vibration test machines incorporate advanced technologies including double-magnetic circuit structure, self-generated skeleton action circles, airborne support, roller bearings with linear guidance, and trunnion isolation systems.
Key Applications
Widely used in defense, weapons, aviation, aerospace, communications, electronics, electrical appliances, and consumer electronics industries for comprehensive product testing and validation.
Technical Specifications
| Model |
Rated Sine Force (N) |
Rated Random Force (N) |
Frequency Range (Hz) |
Rated Acceleration (m/s²) |
Rated Speed (m/s) |
Rated Displacement (p-p) mm |
Max. Loading (Kg) |
Moving Coil (Kg) |
Dimension of Moving Coil (mm) |
| ES-1 | 1000 | 1000 | 3-3500 | 400 | 1.2 | 25 | 70 | 2.5 | Φ150 |
| ES-2 | 2000 | 2000 | 3-3500 | 800 | 1.6 | 25 | 70 | 2.5 | Φ150 |
| ES-2a | 2000 | 2000 | 3-3500 | 300 | 1.6 | 40 | 70 | 8 | Φ230 |
| ES-3 | 3000 | 3000 | 3-3500 | 1000 | 1.6 | 25 | 100 | 3.5 | Φ150 |
| ES-3a | 3000 | 3000 | 3-3500 | 400 | 1.6 | 40 | 120 | 9 | Φ230 |
| ES-6 | 6000 | 6000 | 3-3500 | 1000 | 1.6 | 25 | 180 | 6.5 | Φ230 |
| ES-6a | 6000 | 6000 | 3-3500 | 1000 | 1.6 | 51 | 250 | 12 | Φ230 |
| ES-10 | 10000 | 10000 | 3-3000 | 1000 | 1.8 | 51 | 270 | 14 | Φ240 |
| ES-20 | 20000 | 20000 | 3-3000 | 1000 | 1.8 | 51 | 300 | 30 | Φ320 |
| ES-30 | 30000 | 30000 | 3-2800 | 1000 | 1.8 | 51 | 450 | 40 | Φ450 |
| ES-40 | 40000 | 40000 | 3-2800 | 1000 | 1.8 | 51 | 500 | 50 | Φ450 |
| ES-50 | 50000 | 50000 | 3-2700 | 1000 | 1.8 | 51 | 750 | 50 | Φ450 |
| ES-60 | 60000 | 60000 | 3-2700 | 1000 | 1.8 | 51 | 750 | 60 | Φ450 |
| ES-100 | 100000 | 100000 | 3-2500 | 1000 | 1.8 | 51 | 1000 | 90 | Φ450 |
| ES-120 | 120000 | 120000 | 3-2200 | 1000 | 1.8 | 51 | 1100 | 90 | Φ500 |
| ES-160 | 160000 | 160000 | 3-2100 | 1000 | 1.8 | 51 | 1500 | 150 | Φ600 |
| ES-200 | 200000 | 200000 | 3-2000 | 1000 | 1.8 | 51 | 2500 | 200 | Φ650 |
| ES-350 | 350000 | 350000 | 3-1700 | 1000 | 1.8 | 51 | 4500 | 300 | Φ87 |
High Frequency Vibration Tester Features
- Well-designed dynamic circle skeleton with higher stage axial resonance frequency
- Two-magnetic circuit design with low magnetic flux leakage, compact and rational structure
- Rocker rod roller bearings with straight and import-oriented composite body stiffness orientation for superior eccentric load capacity
- Trunnion isolation foundation for convenient mobile installation
- Advanced technology moving system ensuring high reliability of dynamic circle
- New duct design for enhanced cooling effect
- High static stiffness and small dynamic stiffness balloon bearing, improving vibration table capacity and low-frequency performance
Expander Technical Parameters
Quality Certifications & Packaging
Certifications
- China Official 3rd Party Calibration Report
- CE Certification
Packaging Process
- PP film protective layer
- Vacuum packaging
- Additional PP film coating
- 10mm thickness PU foam for collision protection
- Reinforced plywood case
- Standard ASLI case marking
Customer Support & Services
- High quality guarantee with 12-month warranty
- Professional documentation with shipment
- Custom packaging available with pre-shipment photos
- 48-hour response time with solutions within 3 working days
- Professional engineering after-service support
Company Advantages
- Professional technology support team
- Extensive experience with container loading at Chinese sea ports
- Fast shipment via reputed shipping lines
- Comprehensive after-shipment email support
- 28 years of manufacturing expertise in testing equipment
Quality Certifications
Company Profile
ASLI is a established testing equipment manufacturer with 28 years of experience, specializing in simulation environmental testing equipment and mechanical vibration and shock testing machines. Our mechanical shaker tables are star products with CE certification.
Main Product Lines
Environmental chambers, temperature (humidity) chambers, thermal shock chambers, PCT/Hast chambers (Highly Accelerated Stress Test), ESS chambers, walk-in stability chambers, vacuum ovens, electrodynamic vibration shakers, mechanical shock testers, and environmental combined vibration chambers.
Frequently Asked Questions
Are you a trading company or factory?
We are a factory with 28 years of experience in test instruments and 4 years of exporting experience.
What is the delivery time after order placement?
Generally about 20 days. If we have finished products in stock, we can arrange shipment within 3 days. Production lead times depend on specific items and quantities.
What about warranty and after-sales services?
12 months warranty. After warranty period, our professional after-sale service team provides comprehensive technical support and helps customers solve problems encountered while using our products.
